You wouldn’t think a resin heat shield would make for a particularly photogenic image, but Orion’s partially-submerged heat shield is the exception. There’s an ethereal beauty to the photograph (above), which US Navy divers took of the component’s underside, shortly after the Artemis II mission’s successful splashdown, off the coast of San Diego on April 10, 2026.
The image, released by NASA, isn’t just an important documentation of humanity’s farthest voyage from Earth, it’s vital in assessing the heat shield’s performance for future missions. The disc of Avcoat was all that separated the four astronauts from a blazing 3,000 degrees during re-entry, as the spacecraft hurtled towards earth at 35x the speed of sound.
